PUK SIDE SINGLE - Innovative design combined with functional quality
dimmable - rotatable head - different arm lengths Arm lengths
Puk Side Single, originally a wall luminaire by the renowned manufacturer Top Light, is also suitable for ceiling mounting and is the perfect basis for unusual light and colour compositions. The individually adjustable luminaire head can be used in a targeted manner by means of an arm (rotatable up to 350°) and an adjustment pin. Depending on the glass insert, you can achieve a diffuse mood light when using frosted lenses or clearly delineate light areas with clear lenses. The additional use of colour filters allows you to achieve tasteful lighting effects. Puk Side Single is available with energy-saving LED technology or as a halogen version and is dimmable. The different arm lengths allow additional reliable realisation of your lighting concept.
TOP LIGHT IN STOCK
GENERAL DATA
Colours selectable:
chrome matt / chrome / nickel matt / white-chrome / black-chrome / anthracite-chrome
Light direction: rotatable
Light direction: indirect / direct
Material: metal
Operating voltage: 230V
Protection class: IP20
Lighting Control: BC
Number of heads: 1
DIMENSION
Canopy diameter: 65 mm
Canopy height / depth: 20 mm
Luminaire diameter: 80 mm
Luminaire width: 132,5 mm
Arm lengths selectable: 100 mm / 200 mm / 300 mm / 400 mm / 600 mm
VARIANT DATA: LED / HALOGEN/LED RETROFIT
Light source: 1 x 5 Watt
Illuminant incl.: no
Bulb replaceable:Yes
Socket: G9
maximum lamps: high voltage 1 x 48 Watt
Illuminant recommendation: Phillips 1,8 Watt or halogen max. 48 Watt
Luminous flux(Lumen): 340lm
Light colour(Kelvin): 2800K /
EEK: A+ / A
dimmable: Yes* halogen only
Dimmer: not included
*Please note that the LED Retrofit bulbs are not dimmable.
Manufacturer's item numbers:
| 2-0863-H |
300 mm |
nickel matt |
insert:
2-2025 aluminium reflector / light stop (can only be used under frosted glass!)
2-2026 Lens, clear
2-2026-s Lens, frosted on one side
2-2027 glass, frosted on both sides
Colour filter:
Red 2-2028 red
2-2029 magenta
2-2030 yellow
2-2033 blue
2-2034 green
