Top Light Puk Maxx Wall LED Ø 120 mm wall lamp up- / downlight configurator

Product No.:: 7493
Shipping time:: 3 Weeks (abroad may vary)
Stock:: pieces
Prepayment:: 5 % discount (excl. PP)

Body Colour:

plus remote control for Lightning Control:

Selection Insert top:

Selection Insert bottom:

Equipment color filter top (optional):

Selection color filter bottom:

Selection Lightning Control:

from 205,00 EUR

incl. 19% tax excl. Shipping costs

DESCRIPTION

Rich in versatility thanks to the simple modular principle - Puk Maxx Wall wall luminaire adapts to practically any room situation

Equipped with LED heads, Rolf Ziel stages a puristic realisation. A modern lighting concept is deliberately implemented, which transmits the light compactly and sharply or softly and diffusely into the room, according to taste. The powerful elements of the luminaire skilfully create light accents and appear discreet and reduced despite all their elegance.
The use of different lenses, glasses and - or additional colour filters opens up further possibilities for the play of light.

Item numbers of the mainfacturer:

2-30811 (chrome matt) 2-30812 (chrome) 2-30813 (nickel matt) 2-30812-22 (white matt) 2-30812-02 (black matt) 2-30812-23 (antracite matt) 2-30816 (gold plated chrome)

TECHNICAL DETAILS

GENERAL DATA

Light direction: Fix
Light direction: Indirect
Material: Metal
Operating voltage: 230V
Protection class: IP20
Lighting Control: ABC
Number of heads: 1
Canopy diameter / height: 80 mm x 20 mm
Luminaire diameter / height : 120 mm x 50 mm
Colour selection: Chrome matt / Chrome / Nickel matt / White matt / Black matt / Anthracite matt / 24 Carat gold plated

VARIANT DATA LED

Illuminant: 2 x 12 Watt
Illuminant incl.: Yes
Replaceable bulb: No
Socket: Permanently installed
Maximum lamps: 2 x 12 Watt mains voltage
Luminous flux (lumen): 1800lm
Light colour (Kelvin): 2700K
Energy efficiency class: G

PUK MAXX 120 ACCESSORIES

Optionally selectable, the luminaire body can also be individually configured ( lens, glass, colour filter, Lightning Control)Insert variants: Lens clear / Lens frosted on one side / Glass frosted on both sides ( does not fit under lens )

Colour filters (only under glass or lens): red, magenta, yellow, blue, green

Top Light Lightning Control: ABC
Module A: Integrated, incl. canopy adjustment with module.
Module B: External flush-mounted / wooden wall box, incl. cover plate and module.
Module C: External for any mounting, incl. module.

Remote control: portable + wall bracket black / white

TOP LIGHT WARRANTY

Top Light grants a 5-year factory warranty out of conviction

On all luminaires and their technical function
On all permanently installed LEDs in case of total failure
We reserve the right to make technical changes
Our general terms and conditions still apply
Please find here the current Top Light services on the manufacturer's website
